Containment Solutions for Data Centers
Aisle containment separates the cold supply air a server rack draws in from the hot air it exhausts, so the two never mix. Without it, hot exhaust recirculates into intakes, cooling plant works harder than it should, and capacity is wasted on air that never reaches equipment. Containment is built from wall panels, doors and ceiling systems, which is what we manufacture.
Hot and Cold Aisle Containment Systems
Enclose the supply aisle so conditioned air is delivered only where racks draw it in, allowing higher supply temperatures and reduced fan energy.
Hot Aisle Containment
Capture exhaust at the rear of the racks and return it directly to the cooling plant, keeping the wider white space at a comfortable working temperature.
White Space Partitions
Modular walls that separate data halls, staging areas, electrical rooms and offices, and can be reconfigured as the facility grows.
Sealing the Envelope
Blanking panels, brush grommets, sealed penetrations and tight door seals, because containment only performs as well as its leakage path.
Cleanroom Solutions for Data Centers
At ACH Engineering, we understand that contamination control and airflow management are critical in data centres. These facilities draw large volumes of outside air, and every particle, sulphur-bearing gas and degree of unmanaged heat shortens the life of the hardware inside. From hot and cold aisle containment systems to ISO Class 8 server halls, our modular wall, ceiling and door systems give precise control over air quality, temperature and humidity, protecting equipment while reducing the energy spent cooling it. By applying the same sealed-envelope engineering behind our pharmaceutical cleanrooms, ACH's turnkey solutions help data centres run cleaner, cooler and more efficiently.
Our Data Center Solutions
We provide complete turnkey containment and modular build packages for your facility through manufacturing, supplying, and installing.
Our Professional Data Center Solutions Include:
- Hot & Cold Aisle Containment Systems
- Modular Walls & White Space Partitions
- Suspended / Walkable Ceilings
- Flush Doors & Vision Panels
- HVAC Supply & Installation
- Environmental Monitoring Systems
- Structural & MEP Construction
Every element is manufactured in our own facility and installed by our own crews, so one team is accountable from drawing to handover. Panels arrive precut, which cuts on-site time and dust, and lets work proceed row by row inside a hall that keeps running.
Whether you are building a new data centre, retrofitting containment into an existing raised floor hall, or fitting out an edge deployment, we design the containment around your rack layout and cooling architecture rather than the other way round.
Hot & Cold Aisle Containment
Sealed aisles. No hot air recirculation.
Modular Walls
Reconfigurable partitions for data halls and white space.
Suspended / Walkable Ceilings
Structural ceilings supporting containment roofs.
Flush Doors & Vision Panels
Tight seals with glazed supervision.
HVAC Supply & Installation
Cooling designed around your containment.
Environmental Monitoring
Inlet temperature, humidity, differential pressure.
Structural & MEP Construction
Steel, services and electrical in one package.
Modular Systems We Manufacture and Install
Modular Walls
Prefabricated wall panels engineered to your layout, forming containment enclosures and white space partitions alike.
Walkable Ceilings
Structural ceiling systems that carry access loads and support containment roofs with all services routed above.
Doors
Flush sliding and swing doors with proper seals, forming the ends of contained aisles and the entries to data halls.
Vision Panels
Integrated glazed panels allowing supervision of contained aisles and equipment rooms without breaking the seal.
Monitoring Systems
Continuous inlet temperature, humidity and differential pressure logging with all alarms and remote annunciation.
Semiconductor & Electronics
For all the facilities that also build or service hardware, all ISO classified cleanrooms for electronics assembly and test.
Containment, Fire Safety and Live Sites
Containment changes how a data hall behaves in a fire, and most of these projects happen inside facilities that cannot be shut down. Both need designing for, not discovering.
- Sprinkler coordination: containment roofs specified with drop-away panels or fusible link retention so suppression reaches the racks as the design intends
- Detection coverage: aspirating and point detection reviewed against the enclosed volume, since a sealed aisle is a separate space from the room around it
- Authority approval: containment layout coordinated with the fire protection engineer and local authority before fabrication, not after
- Live site working: phased installation, dust control and out of hours sequencing so the hall keeps running through the build
- Cable and service penetrations: sealed as engineered assemblies, since every gap is bypass airflow and a fire stopping question at once
- Reconfiguration: modular systems demount and relocate as rack density and layout change, without rebuilding from scratch.
