ACH Engineering is a premier Canadian manufacturer providing complete modular cleanroom solutions - delivering both custom-engineered turnkey cleanroom systems and individual cleanroom components for facilities across Vancouver and Metro Vancouver. As a specialized modular cleanroom manufacturer, we engineer, fabricate, deliver, and install controlled environments and replacement hardware compliant with ISO 14644, cGMP, FDA, and industrial quality standards.
Whether your facility requires a high-performance hardwall cleanroom, a flexible softwall cleanroom, a rapid-deploy portable cleanroom or mobile cleanroom, or standalone hardware like cleanroom pass-through boxes, cleanroom air showers, and fan filter units (FFUs), ACH Engineering delivers technical precision designed for Windsor’s industrial landscape.
Serving Key Biotech, Health Science & High-Tech Hubs in Vancouver
We deliver full-scale cleanroom construction, facility expansions, retrofits, and direct component supply tailored to regional manufacturing and life science sectors:
- Vancouver (UBC & Mount Pleasant Life Science Districts): World-class lab space for biopharmaceuticals, gene therapy research, university labs, medical device development, and health tech.
- Burnaby (Discovery Park & SFU): Advanced cleanrooms for semiconductor design, clean energy fuel cell development, optics, and commercial compounding pharmacies.
- Richmond: Specialized food safety and HACCP processing environments, pharmaceutical packaging facilities, and cold storage bio-banks.
- North Vancouver & West Vancouver: Marine technology laboratories, environmental testing enclosures, and analytical chemistry cleanrooms.
Cleanroom Hardware, Components & Architectural Systems
In addition to complete facility builds, ACH Engineering supplies individual cleanroom components for retrofits, facility maintenance, and line expansions in Vancouver. Every component features non-shedding, chemical-resistant materials built to withstand aggressive industrial cleaning.
Cleanroom Wall Panels & Ceilings
- Demountable Cleanroom Walls: Modular, reconfigurable demountable cleanroom walls designed to adapt as production lines change.
- Modular Wall Systems Commercial: Pre-engineered modular wall systems commercial builds with integrated utility raceways and flush finishes.
- Framing & Panels: Non-corrosive aluminum cleanroom framing and heavy-duty steel cleanroom panels engineered for high structural integrity.
- Walkable Ceiling Systems: Structural load bearing cleanroom ceiling frameworks that allow top-side maintenance without interrupting production below, alongside flush cleanroom ceiling grid assemblies.
Flush Cleanroom Doors & Vision Panels
- Cleanroom Doors: Single and double cleanroom doors featuring perimeter gasket seals, interlock controls, and automated drop seals.
- Flush Cleanroom Doors: Seamless flush cleanroom doors that align perfectly level with wall panels to prevent dust and particle accumulation.
- Cleanroom Windows: Flush double-glazed cleanroom windows fitted with internal desiccant to prevent condensation in high-humidity settings.
Contamination Airlocks, Flooring & Coving
- Cleanroom Air Shower: High-velocity cleanroom air shower tunnels that blast particulates off personnel before entering critical assembly zones.
- Cleanroom Pass-Through Chambers: Stainless steel cleanroom pass through units and mechanically interlocked cleanroom pass box cabinets for safe material transfers.
- Epoxy Cleanroom Floor: Non-porous, chemical-resistant epoxy cleanroom floor systems and static-dissipative (ESD) flooring for electronics and battery assembly.
- Cleanroom Coving: Radiused cleanroom coving connecting wall-to-floor, wall-to-wall, and wall-to-ceiling transitions to eliminate 90-degree dirt traps.
Cleanroom Furniture & Industrial Enclosures
- Cleanroom Gowning Bench: Ergonomic cleanroom gowning bench entry dividers separating dirty and clean zones.
- Tables & Workbenches: Heavy-gauge stainless steel cleanroom table units and modular cleanroom bench workstations.
- Sanitation Furniture: Hands-free cleanroom sink units, eyewash stations, and gowning storage.
- Acoustic & Noise Control: Specialty acoustic enclosures , industrial soundproofing panels, modular sound booths, and noise barrier walls outdoor for heavy machinery sound attenuation.
Mechanical Engineering, HVAC & Air Filtration Solutions
Maintaining exact particulate counts and environmental parameters requires robust mechanical design. ACH Engineering provides complete mechanical engineering and replacement HVAC equipment:
Air Filtration & Workstations
- FFU Cleanroom (Fan Filter Unit): Ceiling-integrated FFU cleanroom (fan filter unit) modules equipped with variable speed motors and high-efficiency cleanroom HEPA filter media (99.99% @ 0.3μm).
- Laminar Flow Hood Workstations: Standalone vertical and horizontal laminar flow hood stations for localized, sterile micro-assembly.
- Custom Cleanroom HVAC System Design: End-to-end cleanroom HVAC system design and specialized HVAC for cleanrooms featuring dynamic thermal zoning, dehumidification, and custom ducting.
Pressure Cascades & Air Changes Per Hour
ACH Engineering implements automated controls for cleanroom positive vs negative pressure environments:
- Positive Pressure Cleanrooms: Pushes clean air outward to keep external shop-floor dust and particulates out of critical electronics, optical, or battery processing zones.
- Negative Pressure Cleanrooms: Pulls air inward toward HEPA exhaust systems to safely contain chemical vapors, active powders, or dangerous fumes.
All mechanical systems are engineered according to strict cleanroom air changes per hour chart requirements, from 10–25 ACH for ISO 8 industrial spaces to 240–480 ACH for ISO 5 environments.
ISO Cleanroom Standards & Vancouver Industry Applications
We design, build, and equip cleanroom facilities matching all international standards:
| Industry / Application | ISO & Regulatory Standards | Key Architectural Components & Equipment Supplied |
|---|---|---|
| Biotech & Biopharmaceuticals | GMP cleanroom, cGMP, FDA, ISO 5 to 8 | Flush cleanroom doors, seamless epoxy cleanroom floor, stainless steel cleanroom pass through units. |
| Compounding Pharmacy Cleanroom | USP 797 cleanroom, USP 800 cleanroom, sterile compounding cleanroom | Positive/negative pressure airlocks, FFU cleanroom ceiling grids, containment exhaust hoods, hands-free cleanroom sink. |
| Semiconductor & Clean Energy | ISO 5 cleanroom, Class 100 cleanroom, ESD Control | Conductive flooring, non-magnetic aluminum cleanroom framing, static-dissipative wall panels. |
| Medical Device Manufacturing | ISO 7 cleanroom, ISO 8 cleanroom, Class 10000 cleanroom | Demountable cleanroom walls, high-velocity cleanroom air shower corridors, double-glazed vision panels. |
| Food Processing & Agritech | HACCP, cGMP, FDA | Washdown-rated panels, stainless steel workstations, antimicrobial floor coatings. |
Frequently Asked Questions
1. Does ACH Engineering provide cleanroom components and equipment in Vancouver?
Yes. In addition to turnkey cleanroom design and installation, we supply individual cleanroom hardware throughout Vancouver, Burnaby, and Richmond. This includes cleanroom pass-throughs, air showers, replacement fan filter units (FFUs), flush cleanroom doors, wall panels, and stainless steel lab benches.
2.What is the difference between softwall vs hardwall cleanrooms?
A hardwall cleanroom utilizes rigid modular wall panels (steel, aluminum, or FRP) to create a sealed, pressure-controlled space required for ISO 5–7, cGMP, or EV battery dry room standards. A softwall cleanroom uses flexible, clear PVC strip curtains hung from a steel or aluminum frame; it offers a portable, cost-effective choice for localized ISO 7–8 process protection where strict pressure containment is not required.
3.What is the difference between ISO 7 and ISO 8 cleanrooms?
The primary difference between ISO 7 and ISO 8 comes down to allowable particle counts and air exchange rates. An ISO 7 environment permits a maximum of 352,000 particles (≥0.5 μm) per cubic meter and requires 30 to 60 air changes per hour. An ISO 8 cleanroom permits up to 3,520,000 particles (≥0.5 μm) per cubic meter and requires 10 to 25 air changes per hour.
4.What is involved in the cleanroom validation and certification process?
Our engineering specialists handle the entire cleanroom certification process and perform complete cleanroom validation protocol testing (IQ/OQ/PQ). This includes testing HEPA filter integrity (PAO leak testing), verifying particle counts, measuring airflow velocities, testing pressure differentials, and documenting compliance for quality audits.
